Vertical Clamping Horizontal Injection Molding Machine Tie-bar less Series

YC SERIES

Product Feature
  • Vertical clamping, without machine column design, the mechanical constitutive property is strong, Injection powerfully, suit large-scale embedment to take shape the processing.
  • Three-sides open space, easier operation for embedded parts and finished products, and able to combine automation connecting planning.
  • The height of operating surface is ergonomic, and the height of the machine is low. The operating environment can have more additional space to use.
  • Variety of logic design complies with the customer’s requirement.
Main specifications

Swipe the table to see more informations

Model

INJECTION UNIT
Screw Diameter
(mm)
Injection Pressure
(kgf / cm2)
Injection Capacity
(cm3)
Max. Injection Weight
(gr)
Max. Injection Weight
(oz)
Injection Rate
(cm3 / sec)
CLAMPING UNIT
Clamping Force
(tf)
Clamping Stroke
(mm)
Max. Open Distance
(mm)
Min. Mold Height
(mm)
Mold Size
(mm)
Hydraulic Ejector Force
(tf)
Ejector Stroke
(mm)
Height of Nozzle Center
(mm)
Distance Form Mold Center to Nozzle
(mm)
SLIDE UNIT
Slide Stroke
(mm)
Slide Dimension
(mm)
ROTARY UNIT
Rotary Dimension
(mm)
OTHER
Drive Motor
(kw)
Heater
(kw)
Oil Tank Capacity
(L)
Dimension of Machine : L
Dimension of Machine : W
Dimension of Machine : H
Weight of Machine
(T)
Inquiry
YC-40
V 2S R

28 & 36
2008 & 1215
83 & 137
74 & 123
2.6 & 4.3
47 & 78

40
200
375
175
420 / 240
1.7
突出 40
140 ± 25
min 75

450
870 × 240

    Φ 750

5.5 (7.5) 5.5+2.2 (7.5+3)
4.5
200
2.5 2.6 3.0
1.3 1.4 1.4
2.5 2.6 2.7
3.5 4.0 4.8
YC-60
V 2S R

32 & 40
1914 & 1225
124 & 194
112 & 175
3.9 & 6.1
56 & 92

60
200
400
200
480 / 280
1.7
突出 40
140 ± 25
min 75

500
980 × 280

    Φ 856

7.5 (10) 7.5+2.2 (10+3)
6
220
2.7 2.8 3.3
1.3 1.4 1.4
2.6 2.7 2.8
4.1 4.6 5.5
YC-90
V 2S R

34 & 42
1931 & 1265
149 & 228
134 & 205
4.7 & 7.2
67 & 108

90
250
500
250
580 / 380
2.7
突出 40
150 ± 25
min 125

600
1180 × 380

    Φ 980

11.1 (15) 11.1+2.2 (15+3)
7.5
250
2.9 3.0 3.7
1.5 1.6 1.6
2.7 2.8 2.9
5.5 6.0 7.2
YC-120
V 2S R

38 & 50
2079 & 1200
204 & 353
183 & 319
6.4 & 11.1
81 & 141

120
300
550
250
650 / 420
2.7
突出 40
150 ± 25
min 125

650
1290 × 420

    Φ 1172

14.9 (20) 14.9+2.2 (20+3)
9.5
300
3.0 3.1 4.2
1.6 1.7 1.7
3.0 3.0 3.1
7.0 7.8 9.5

*Specifications are subject to change without notice.
*Screw and clamping force are optional.
